Maintenance and Service Guide 4–1
4
Removal and Replacement
Preliminaries
This chapter provides essential information for proper and safe
removal and replacement service.
4.1 Tools Required
You need the following tools to complete the removal and
replacement procedures:
■ Magnetic screw driver
■ Phillips P0 screw driver
■ Torx8 screw driver
■ Torx7 pin bit screw driver
✎
Some computer models have two Torx7 with pin security screws
(M2.0×4.0) securing the Mini PCI communications board to the
computer. A T7 pin bit screw driver is required to remove the
Mini PCI communications board on these computer models.
Refer to Section 5.12, “Mini PCI Communications Board,” for
more information on removing Mini PCI communications boards.
■ 5.0-mm socket for system board standoffs
■ Flat-bladed screwdriver
