1–22 Maintenance and Service Guide
Product Description
3 Power connector Connects an AC adapter or an optional
Automobile Power Adapter/Charger or
Aircraft Power Adapter.
4 Serial connector Connects an optional serial device.
5 Parallel connector Connects an optional parallel device, such
as an external diskette drive or a printer.
6 S-Video out jack Connects an optional S-Video device, such
as a television, VCR, camcorder, overhead
projector, or video capture card.
7 External monitor
connector
Connects an optional external monitor or
overhead projector.
8 RJ-45 jack Connects a network cable.
9 Intake vents (2) Enable airflow to cool internal components.
Ä
To prevent overheating, do not
obstruct vents. Using the notebook
on a soft surface, such as a pillow,
blanket, rug, or thick clothing, can
block airflow.
10 Security cable slot Attaches an optional security cable to the
notebook.
✎
The purpose of security solutions
is to act as a deterrent. These
solutions do not prevent the
product from being mishandled or
stolen.
11 Optical disk drive Reads and records CD and DVD media.
12 Battery bay Holds the primary battery pack. The battery
pack ships outside the notebook.
Table 1-5
Rear and Left-Side Components
(Continued)
Item Component Function
