Illustrated Parts Catalog
Maintenance and Service Guide 3–17
345058-001 Display assembly, 15.0-inch, XGA, TFT
345059-001 Display assembly, 15.0-inch, SXGA+, TFT
345060-001 Display assembly, 15.0-inch, UXGA+, TFT
345061-001 Top cover (includes TouchPad and speaker)
345062-001 Base enclosure (includes optical drive shield, hard drive
shield, and four notebook feet)
345063-001 LED switch cover
345064-001 System board (includes 64-MB discrete video memory)
345065-001 Fan assembly
345066-001 Misc Plastics Kit
345067-001 Heat sink
345630-001 40-GB (5400-rpm) hard drive
345631-001 60-GB (5400-rpm) hard drive
345632-001 80-GB (5400-rpm) hard drive
345640-001 802.11b wireless LAN (ROW) Wireless LAN card
345641-001 802.11b wireless LAN (MOW) Wireless LAN card
345855-001 60-GB (7200-rpm) hard drive (nw8000 only)
345856-001 Trusted Platform Module (TPM)
345857-001 Intel Pentium M (Dothan) processor, 1.8 GHz
348277-001 Bluetooth wireless communications board
349206-001 System board (includes 128-MB discrete video memory)
349240-001 24X Max CD-ROM Drive
349241-001 8X Max DVD-ROM drive
Table 3-6
Spare Parts: Sequential Part Number Listing
(Continued)
Spare Part
Number Description
To Next Page
