Service Reference Guide, dc5750 437963-001 7–27
Removal and Replacement Procedures— Small Form Factor (SFF) Chassis
7.15 Spea ke r
1. Prepare the computer for disassembly (Section 7.1).
2. Remove the access panel(Section 7.3).
3. Remove the fan shroud (Section 7.11).
4. Disconnect the speaker wire from the system board.
5. Remove the two screws that secure the speaker to the chassis 1, then lift the speaker up and
out of the chassis 2.
To install the speaker, reverse the removal procedures.

HP COMPAQ DC5750 Specifications

General

Processor Speed	Up to 2.8 GHz
Chipset	ATI Radeon Xpress 1150
Memory	Up to 4 GB DDR2 SDRAM
Audio	Integrated High Definition Audio
Network	Integrated Broadcom NetXtreme Gigabit Ethernet
Processor	AMD Athlon 64 X2 / AMD Sempron
Storage	SATA Hard Drive
Optical Drive	DVD-ROM, DVD+/-RW
Operating System	Windows XP Professional
Form Factor	Small Form Factor or Microtower
USB Ports	8 USB 2.0 (2 front, 4 rear, 2 internal)
