Hardware Reference Guide www.hp.com A–1
A
Specifications
HP Compaq Convertible Minitower
Desktop Dimensions
Height
Width
Depth (depth will increase if the computer is
equipped with a port security bracket)
6.6 in
17.65 in
17.8 in
16.7 cm
44.8 cm
45.2 cm
Tower Dimensions
Height
Width
Depth (depth will increase if the computer is
equipped with a port security bracket)
17.65 in
6.6 in
17.8 in
44.8 cm
16.7 cm
45.2 cm
Approximate Weight 35 lb 15.9 kg
Weight Supported (maximum distributed
load for Desktop configuration only)
100 lb 45.5 kg
Temperature Range
Operating
Nonoperating
50° to 95°F
-22° to 140°F
10° to 35°C
-30° to 60°C
Relative Humidity (noncondensing)
Operating
Nonoperating (38.7°C max wet bulb)
10-90%
5-95%
10-90%
5-95%
Maximum Altitude (unpressurized)
Operating
Nonoperating
10,000 ft
30,000 ft
3048 m
9144 m
Operating temperature is derated 1.0° C per 300 m (1000 ft) to 3000 m (10,000 ft) above
sea level, no direct sustained sunlight. Maximum rate of change is 10° C/Hr. The upper limit
may be limited by the type and number of options installed.

Table of Contents

Other manuals for HP Compaq dc7100 MT

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Compaq dc7100 MT and is the answer not in the manual?

HP Compaq dc7100 MT Specifications

General IconGeneral
GraphicsIntegrated Intel Graphics Media Accelerator 900
NetworkIntegrated Broadcom NetXtreme Gigabit Ethernet
Operating SystemWindows XP Professional
Form FactorMicrotower
ProcessorIntel Pentium 4
ChipsetIntel 915G Express
MemoryUp to 4 GB DDR2 SDRAM
Storage40 GB to 160 GB SATA
Optical DriveDVD-ROM
PortsUSB 2.0, serial, parallel, audio in/out
Expansion Slots1 PCI Express x16
AudioIntegrated AC'97 audio
