Upgrading and replacing hardware
20 Evo D310 Micro Desktop
Installing or replacing an AGP or PCI accessory card
1 Switch off the PC and remove the PC’s cover. Refer to page 10.
2 Remove the retaining bracket.
3 Remove the slot cover and store it in a safe place in case you need it again or, if replacing a card,
remove the card.
4 If your are installing or replacing an AGP card, open the small latch located at the end of the slot.
5 Aligning the card carefully, slide it into position and press it firmly into the slot. If you are installing or
replacing an AGP card, close the latch located at the side of the slot.
6 Replace the retaining bracket.
7 Replace the cover. Refer to page 10.
