Upgrading and replacing hardware
14 Evo D310 Micro Desktop
Replacing the hard drive
WARNING
For your safety, disconnect the power cord and all external cables.
1 Switch off the PC and remove the PC’s cover and front panel. Refer to page 10.
2 Locate the hard drive and taking hold of the two large plastic latches that secure the bay, swing the
device bay upwards.
3 Detach the data and power cables from the hard drive.
4 Standing at the rear of the PC, press the two tabs securing the hard drive inwards and carefully slide
the drive tray towards you and out of the PC.
Primary Hard drive
Left latch
Right latch
Rear of the PC
