5–14 Maintenance and Service Guide
Removal and Replacement Procedures
3. Loosen the Phillips PM2.0×4.0 screw 1 that secures the
memory module compartment cover to the computer.
4. Lift the right side of the cover 2 and swing it up and to
the left.
5. Remove the memory module compartment cover.
✎
The memory module compartment cover is included in the
Plastics Kit, spare part number 417527-001.
Removing the Memory Module Compartment Cover
