Removal and Replacement Procedures
Maintenance and Service Guide 5–3
5.2 Disassembly Sequence Chart
Use the chart below to determine the section number to be
referenced when removing computer components.
Disassembly Sequence Chart
Section Description
# of Screws Removed
5.3 Preparing the Computer for
Disassembly
Battery
0
0
5.4 Hard Drive 2 loosened to remove the
hard drive cover
1 loosened to remove the
hard drive
4 to disassemble hard drive
5.5 Computer Feet 0
5.6 Optical Drive 1 to remove the optical drive
2 to remove the optical drive
bracket
5.7 External Memory Module 1 loosened to remove the
memory module
compartment cover
5.8 Bluetooth Module 1 loosened to remove the
Bluetooth module cover
2 removed to remove
Bluetooth module
5.9 Keyboard 2
5.10 Fan Assembly 4 loosened on fan assembly
4 removed on thermal plate
5.11 Heat Sink 4 loosened
5.12 Processor 1 loosened
To Next Page
