Product Description
Maintenance and Service Guide 1–19
Table 1-8
Bottom Components
Item Component Function
1 Battery bay Holds the battery.
2 Battery release latches (2) Secure the battery in the battery bay.
3 Accessory battery
connector
Connects an optional HP Ultra-Capacity
Battery or HP Extended Life Battery.
4 Memory module
compartment
Contains one memory slot that supports
replaceable memory modules.
5 Hard drive bay Holds the primary hard drive.
6 Docking connector Connects the computer to an optional
docking device.
7 Exhaust vent Provides airflow to cool internal
components.
Ä
To prevent overheating, do not
obstruct vents. Use the computer
only a hard, flat surface. Do not
allow a hard surface, such as an
adjoining printer, or a soft
surface, such as pillows or thick
rugs or clothing, to block airflow.
