5–36 Maintenance and Service Guide
Removal and Replacement Procedures
5.15 TouchPad
1. Prepare the computer for disassembly (Section 5.3).
2. Remove the keyboard (Section 5.9).
3. Turn the computer upside down with the front toward you.
4. Remove the Torx8 T8M2.5×10.0 screw that secures the
TouchPad to the computer.
Removing the TouchPad Screw
TouchPad Spare Part Number Information
TouchPad with 3 TouchPad buttons
TouchPad with 2 TouchPad buttons
382675-001
382676-001
To Next Page
