Removal and Replacement Procedures
Maintenance and Service Guide 5–45
5.18 Display Assembly
1. Prepare the computer for disassembly (Section 5.3)
and remove the following components:
a. Keyboard (Section 5.9)
b. Switch cover (Section 5.17)
c. TouchPad (Section 5.15)
Display Assembly Spare Part Number Information
15.4-inch, WUXGA
15.4-inch, WSXGA
15.4-inch, WXGA+
416413-001
416412-001
416411-001
