5–42 Maintenance and Service Guide
Removal and Replacement Procedures
5.17 Switch Cover
✎
Both switch cover spare part kits include the LED board and
LED board cable.
1. Prepare the computer for disassembly (Section 5.3).
2. Remove the keyboard (Section 5.9).
3. Turn the computer upside down with the rear panel
toward you.
4. Remove the 3 Phillips PM2.0×2.0 screws that secure the
switch cover to the computer.
Removing the Switch Cover Screws
Switch Cover Spare Part Number Information
For use with nw8440 and nc8430 models
For use with nx8420 models
416405-001
416406-001
To Next Page
