1–10 Maintenance and Service Guide
Product Description
The external components on the left side of the computer are
shown below and described in Table 1-4.
Left-Side Components
Table 1-4
Left-Side Components
Item Component Function
1 Security cable slot Attaches an optional security cable to the
computer.
Ä
Security solutions are designed to
act as deterrents. These deterrents
may not prevent a product from being
mishandled or stolen.
2 RJ-45 (network) jack Connects an optional network cable.
3 RJ-11 (modem) jack Connects the modem cable.
4 S-Video-out jack Connects an optional S-Video device, such
as a television, VCR, camcorder, projector,
or video capture card.
