Removal and Replacement Procedures
Maintenance and Service Guide 5–21
4. Turn the computer display side up with the front toward you.
5. Open the computer as far as possible.
6. Slide the four keyboard retention tabs 1 toward you. The tabs
are located between the
esc and f1 keys, between the f4 and f5
keys, between the
f8 and f9 keys, and between the f12 and
delete keys.
7. Lift the rear edge of the keyboard 2 and swing it toward
you until it rests on the palm rest.
Releasing the Keyboard
