Specifications
Maintenance and Service Guide 6–5
Table 6-4
15.4-inch, WXGA+WVA
Dimensions
Height
Width
Diagonal
20.7 cm
33.1 cm
39.1 cm
8.1 in
13.0 in
15.4 in
Number of colors Up to 16.8 million
Contrast ratio 200:1
Brightness 180 nits typical
Pixel resolution
Pitch
Format
Configuration
0.259 × 0.259 mm
1440 × 900
RGB vertical stripe
Backlight CCFT
Character display 80 × 25
Total power consumption 6.5 W
Viewing angle +/-45° horizontal, +15/-35° vertical typical
