HP Compaq nc8430

A–6 Maintenance and Service Guide
Screw Listing
Torx8 T8M2.5×4.0 Screw Locations
Table A-4
Torx8 T8M2.5×4.0 Screw
(Continued)
Color Qty. Length Thread
Head
Width
Black 13 4.0 mm 2.5 mm 5.0 mm
Where used:
5 screws that secure the top cover to the computer (documented in
Section 5.19)
mm
