HP Compaq nc8430

A–16 Maintenance and Service Guide
Screw Listing
Phillips PM2.0×8.0 Captive Screw Locations
Table A-9
Phillips PM2.0×8.0 Captive Screw
Color Qty. Length Thread
Head
Width
Silver 4 8.0 mm 2.0 mm 5.0 mm
Where used:
4 captive screws that secure the heat sink to the computer (documented in
Section 5.11)
mm
