Removal and Replacement Procedures
Maintenance and Service Guide 5–5
3. Remove the battery pack by following these steps:
a. Turn the computer bottom side up with the left side
facing forward.
b. Slide and hold the battery release latch
1
toward the back
of the computer (Figure 5-2).
c. Use the notch in the battery bay to slide the battery pack
out of the battery bay
2
.
d. Remove the battery pack.
Figure 5-2. Releasing the Battery Pack
Reverse the preceding procedures to install the battery pack.
Battery Packs
Spare Part Number Information
8 cell, 62 W hour, 4.0 Ah, Li ion
8 cell, 58 W hour, 3.6 Ah, Li ion
289053-001
281766-001
