Removal and Replacement Procedures
Maintenance and Service Guide 5–47
5.18 Charger Board
1. Prepare the computer for disassembly (Section 5.3).
2. Remove the palm rest (Section 5.14).
Charger Board
Spare Part Number Information
Charger board
The charger board shield is included in the Miscellaneous
Plastics/Hardware Kit, spare part number 285541-001.
285525-001
