5–60 Maintenance and Service Guide
Removal and Replacement Procedures
5.23 Modem Cable
✎
The modem cable is included in the Miscellaneous Cable Kit,
spare part number 285540-001.
1. Prepare the computer for disassembly (Section 5.3) and
remove the following components:
a. LED cover (Section 5.9)
b. Keyboard (Section 5.10)
c. Heat spreader (Section 5.11)
d. Display (Section 5.13)
e. Palm rest (Section 5.14)
f. Top cover (Section 5.20)
g. Fan (Section 5.21)
h. System board (Section 5.22)
