Removal and Replacement Procedures
Maintenance and Service Guide 5–13
5.4 Computer Feet
The computer feet are adhesive-backed rubber pads. The
computer feet are included in the Miscellaneous
Plastics/Hardware Kit, spare part number 285541-001. The
computer feet attach to the base enclosure as illustrated in
Figure 5-9.
Figure 5-9. Replacing the Computer Feet
5.5 Memory Expansion Board
1. Prepare the computer for disassembly (Section 5.3).
2. Turn the computer bottom side up with the front facing
forward.
Memory Expansion Boards
Spare Part Number Information
512 MB
256 MB
128 MB
285524-001
285523-001
285222-001
