5–14 Maintenance and Service Guide
Removal and Replacement Procedures
3. Remove the PM2.5 × 4.0 screw
1
that secures the memory
expansion compartment cover to the base enclosure
(Figure 5-10).
4. Slide the cover to the right
2
.
5. Lift the right edge of the cover and swing it to the left
3
.
6. Remove the cover.
Figure 5-10. Removing the Memory Expansion
Compartment Cover
✎
Memory expansion compartment covers are available with carbon
finish for Evo Notebook N1020v and N1000v models and silver
finish for Presario 1500 models, and are included in the
Miscellaneous Plastics/Hardware Kit, spare part number
285541-001.
