5–4 Maintenance and Service Guide
Removal and Replacement Procedures
5.3 Preparing the Computer for
Disassembly
Perform the following steps before disassembling the computer:
1. Turn off the computer.
2. Disconnect the AC adapter and all external devices.
Section Description # of Screws Removed
5.16 TouchPad and TouchButton 4 on TouchPad models
5 on Dual Stick models
5.17 Display release assembly 2
5.18 Charger board 3
5.19 Speaker assembly 0
5.20 Top cover 5
5.21 Fan 0
5.22 System board 7
5.23 Modem cable 1
Disassembly Sequence Chart
(Continued)
To Next Page
