Removal and Replacement Procedures
Maintenance and Service Guide 5–25
5.11 Heat Spreader
1. Prepare the computer for disassembly (Section 5.3).
2. Remove the LED cover (Section 5.9).
3. Remove the keyboard (Section 5.10).
Heat Spreaders
Spare Part Number Information
For use only on Evo Notebook N1020v and N1000v models
For use only on Presario 1500 models
291648-001
285544-001
