HP Compaq Presario,Presario 1500

Removal and Replacement Procedures
Maintenance and Service Guide 5–53
✎
After the top cover is removed, the system board-to-TouchButton
board cable can be removed. The system board-to-TouchButton
board cable is included in the Miscellaneous Cable Kit, spare part
number 285540-001.
10. Release the ZIF connector
1
to which the system
board-to-TouchButton board cable is attached and disconnect
the cable
2
from the system board (Figure 5-41).
Figure 5-41. Removing the System Board-to-TouchButton
Board Cable
Reverse the preceding procedures to install the top cover.
