6–10 Maintenance and Service Guide
Specifications
Table 6-7
DVD-ROM Drive
Applicable disk DVD-5, DVD-9, DVD-10
CD-ROM (Mode 1 and 2)
CD Digital Audio
CD-XA ready (Mode 2, Form 1 and 2)
CD-I ready (Mode 2, Form 1 and 2)
CD-R (read only)
CD Plus
Photo CD (single/multisession)
CD-Bridge
Center hole diameter 1.5 cm .59 in
Disk diameter 12 cm, 8 cm
Disk thickness 1.2 mm .047 in
Track pitch .74 µm
Access time (typical reads, including setting)
Random (DVD media)
Full stroke (DVD media)
Random (CD media)
Full stroke (CD media)
< 125 ms
< 225 ms
< 100 ms
< 175 ms
Audio output level Line-out, 0.7 to 0.9 Vrms
Cache buffer 512 KB
Data transfer rate (typical, including setting)
Max 24X CD
Max 8X DVD
3600 KB/s (150 KB/s at 1X CD rate)
10,800 KB/s (1352 KB/s at 1X
DVD rate)
Startup time < 12 seconds (typical)
Stop time < 3 seconds
