C–14 Maintenance and Service Guide
Figure C-13. TM2.5 × 14.0 Shoulder Screw Locations
Table C-5
Torx T8 Metric 2.5 × 14.0 Shoulder Screw
Color Qty Length Thread
Head
Width
Silver 4 14.0 mm 2.0 mm 6.0 mm
Where used:
Four screws that secure the heat spreader to the base enclosure
(documented in Section 5.11)
