1–38 Maintenance and Service Guide
Product Description
The external components on the bottom of the computer are
shown in Figure 1-6 and described in Table 1-9.
Figure 1-6. Bottom Components
Table 1-9
Bottom Components
Item Component Function
1 Connector cover Protects the parallel, external
monitor, external keyboard/mouse,
and USB connectors.
2 Docking connector Connects the computer to an
optional port replicator.
