Illustrated Parts Catalog
Maintenance and Service Guide 3–19
Table 3-2
Miscellaneous Plastics/Hardware Kit Components
Spare Part Number 285541-001
Item Description Item Description
1 Left hinge cover 8 PC Card space saver
2 Right hinge cover 9 *Connector cover
3 *Display release assembly 10 *Hard drive bracket
4 TouchPad bracket 11 *Mini PCI compartment cover
5 Charger board shield 12 *Memory expansion
compartment cover
6 Optical drive rear
alignment rail
13 *Battery bezel
7 Optical drive front
alignment rail
14 Computer feet
*Includes two of each part, one with carbon finish for use with Evo Notebook
N1020v and N1000v models and one with silver finish for use with
Presario 1500 models
