5–6 Maintenance and Service Guide
Removal and Replacement Procedures
c. Press the PC Card release button 1 to release the button
from the base enclosure. Press the button a second time to
eject the contents of the PC Card slot.
d. Remove the PC Card slot device
2 from the card slot.
✎
The PC Card slot space saver and SD Card slot space saver are
included in the Miscellaneous Plastics/Hardware Kit, spare
part number 348350-001.
e. Press the PC Card release button again 1 to reset it.
Removing the PC Card Device (space saver shown)
