Removal and Replacement Procedures
Maintenance and Service Guide 5–9
9. Remove the Mini PCI communications board by following
these steps:
a. Remove the 2 PM2.0 × 4.0 screws
1 that secure the Mini
PCI communications/memory module slot cover to the
tablet PC.
b. Lift the back edge of the Mini PCI communications/
memory module slot cover up and swing it toward you
2.
c. Remove the Mini PCI communications/memory module
slot cover.
Removing the Memory Module/Mini PCI Communications
Compartment Cover
Mini PCI Communications Board
Spare Part Number Information
Wireless local area network (LAN) card 348997-001 (802.11b MOW)
348996-001 (802.11b ROW)
374157-001 (802.11b/g MOW)
374158-001 (802.11b/g ROW)
349985-001 (802.11 a/b/g)
