Removal and Replacement Procedures
Maintenance and Service Guide 5–29
11. Remove the system main memory by following these steps:
a. Spread the retaining tabs
1 securing the main
memory board to the system board.
The end of the memory board opposite the connector rises
at a 45-degree angle.
b. Pull the memory module away from the connector at a
45-degree angle
2.
Removing the Main Memory Module
