Removal and Replacement Procedures
Maintenance and Service Guide 5–31
13. Remove the keyboard release assembly by following these
steps:
a. Remove the 4 TM2.5 × 6.0 screws
1 that secure the
keyboard release assembly to the base enclosure.
b. Lift the keyboard release assembly straight up
2 and
remove it from the base enclosure.
Removing the Keyboard Release Assembly
