HP Compaq tc1100

C–14 Maintenance and Service Guide
Screw Listing
Torx M2.5 × 8.0 Screw Locations
Table C-10
Torx M2.5 × 8.0 Screw
Color Qty. Length Thread
Head
Width
Silver 5 8.0 mm 2.5 mm 4.3 mm
Where used:
1 2 screws that secure the docking station pivot arm and cable bracket to the
bottom case (documented in Section 5.9)
2 3 screws that secure the docking station pivot arm hinge to the bottom case
(documented in Section 5.9)
mm
