Screw Listing
Maintenance and Service Guide C–15
Phillips M2.5 × 12.0 Screw Location
Table C-11
Phillips M2.5 × 11.0 Screw
Color Qty. Length Thread
Head
Width
Silver 1 11.0 mm 2.0 mm 4.3 mm
Where used:
1 screw that secures the docking station pivot arm hinge to the bottom case
(documented in Section 5.9)
mm
