4 Docking connector Connects to the tablet PC.
5 Docking restraint latch Secures the tablet PC to the docking stand.
6 Docking alignment
brackets (2)
Fit into the tablet PC docking alignment
slots to align the tablet PC in the docking
stand.
7 Security cable slot Attaches an optional security cable to the
tablet PC.
Ä
The purpose of security solutions is
to act as a deterrent. These solutions
do not prevent the product from being
mishandled or stolen.
8 MultiBay release lever Ejects a MultiBay device from the bay.
9 External MultiBay
connector
Connects optional USB devices.
Table 1-56
Docking Station Upper and
Right-Side Components
(Continued)
Item Component Function
To Next Page
