Introducing the switches | 19
Fan requirements
Switches Fan Tray 1 Fan Tray 2
JL658A Required Required
JL659A Required Required
JL663A Required Optional
JL664A Required Optional
JL660A Required Optional
JL661A Required Optional
JL662A Required Optional
JL762A Required Required
R8S89A Required Required
R8S90A Required Required
R8S91A Required Required
R8S92A Required Required
S0E91A Required Required
S0X44A Required Required
For JL660A, JL661A, JL662A, JL663A, and JL664A:
Fan Condition Fan Speed Fan Redundancy Shutdown
System installed with 2 fan trays
4 fans functioning
normally
According to ambient and
component temperature
N+1 Component hits thermal limit
1 fan fault Remaining fans will spin at Max
speed
Not supported Component hits thermal limit
More than 1 fan
fault
Remaining fans will spin at Max
speed
Not supported Upon detection, system will be
shut down in 3 minutes or
component hits thermal limit
System installed with 1 fan tray
2 fans functioning
normally
According to ambient and
component temperature
Not supported Component hits thermal limit
1 fan fault Remaining fans will spin at Max
speed
Not supported Upon detection, system will be
shut down in 3 minutes or
component hits thermal limit
