HP DesignJet Z5200 series

10. Lift the Window vertically out of the printer.
Front Cover
Removal
NOTE: Switch off the printer and remove the power cable.
1. Squeeze each of the four attachment clips under the Front Cover, to release the cover from the
printer.
2. Carefully pull the bottom of the Front Cover forwards until you can release it from its attachments.
ENWW Front Cover 177
