3. Unhook the Front Cover from the four attachments and remove it from the printer.
Media Output Assembly
Removal
NOTE: Switch off the printer and remove the power cable.
1. Remove the Front Cover (refer Front Cover on page 177).
2. Remove four T-15 screws that secure the Media Output Assembly to the printer.
3. Release the four attachment clips.
178 Chapter 6 Removal and Installation ENWW
