2-7
Installing the E-MSM720
Installation Procedures
WARNING For safe reliable installation, only use the screws provided in the
accessory kit to attach the mounting brackets to the E-MSM720.
2. Hold the E-MSM720 with attached brackets up to the rack and move it
vertically until rack holes line up with the bracket holes, then insert and
tighten the four number 12-24 screws holding the brackets to the rack.
Figure 2-4. Mounting in a rack
