HP Elite Dragonfly G2 User Manual

2 Components
Your computer features top-rated components. This chapter provides details about your components, where
they are located, and how they work.
Right
Use the illustration and table to identify the components on the right side of the computer.
Table 2-1 Right-side components and their descriptions
Component Description
(1) Battery light When AC power is connected:
● White: The battery charge is greater than 90%.
● Amber: The battery charge is from 0 to 90%.
● O: The battery is not charging.
When AC power is disconnected (battery not charging):
● Blinking amber: The battery has reached a low battery
level. When the battery has reached a critical battery level,
the battery light begins blinking rapidly.
● O: The battery is not charging.
(2)
USB Type-C
®
power connectors and
Thunderbolt™ ports with HP Sleep and Charge
(2)
Connects an AC adapter that has a USB Type-C connector,
supplying power to the computer and, if needed, charging the
computer battery.
– and –
Connects a USB device, provides high-speed data transfer, and
charges small devices (such as a smartphone), even when the
computer is o.
NOTE: Use a standard USB Type-C charging cable or cable
adapter (purchased separately) when charging a small external
device.
– and –
Connects a display device that has a USB Type-C connector,
providing DisplayPort™ output.
NOTE: Your computer might also support a Thunderbolt
docking station.
Right 5

HP Elite Dragonfly G2 Specifications

General

4G standard	LTE-TDD & LTE-FDD
Antenna type	2x2
Wi-Fi standards	Wi-Fi 6 (802.11ax)
Bluetooth version	5.0
WLAN controller model	Intel Wi-Fi 6 AX201
Mobile network connection	Yes
Mobile network generation	4G
WLAN controller manufacturer	Intel
Color gamut	72 %
Display surface	Gloss
RGB color space	NTSC
Display diagonal	13.3 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	400 cd/m²
Display diagonal (metric)	33.8 cm
Processor cache	8 MB
Processor cores	4
Processor model	i5-1135G7
Processor family	Intel® Core™ i5
Processor threads	8
Configurable TDP-up	28 W
Processor frequency	- GHz
Processor cache type	L3
Configurable TDP-down	12 W
Processor boost frequency	4.2 GHz
Configurable TDP-up frequency	2.4 GHz
Configurable TDP-down frequency	0.9 GHz
ECC	No
Memory slots	1x SO-DIMM
Internal memory	8 GB
Memory clock speed	4266 MHz
Memory form factor	On-board
Internal memory type	LPDDR4x-SDRAM
Battery weight	240 g
Battery capacity	56 Wh
Pointing device	Clickpad
Input device model	HP Premium Collaboration Keyboard
Keyboard special features	Spill-resistant
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express, NVMe
Storage media	SSD
Total storage capacity	256 GB
Number of SSDs installed	1
Color name	Galaxy blue
Form factor	Convertible (Folder)
Product type	Hybrid (2-in-1)
Product color	Blue
Country of origin	China
Market positioning	Premium
Original brand name	HP
Speakers manufacturer	Bang & Olufsen
Charging port type	USB Type-C
USB 2.0 ports quantity	0
Sustainability certificates	ENERGY STAR, TCO
HP segment	Business
Operating system installed	Windows 11 Pro
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Front camera	-
Password protection type	BIOS, Power on, User
Trusted Platform Module (TPM) version	2.0
Package depth	449 mm
Package width	69 mm
Package height	305 mm

Weight and Dimensions

Depth	197.5 mm
Width	304.3 mm
Height	16.1 mm
Weight	990 g
