2. Insert a nonmarking, nonconductive, thin tool near the hinge (1) and pull up to release the cover (2).
3. Remove the bottom cover from the computer (3).
To replace the bottom cover, reverse the removal procedures.
Battery
To remove the battery, use this procedure and illustration.
Table
5-2 Battery description and part number
Description Spare part number
Battery, 4 cell, 56 Whr L52581-005
Battery, 2 cell, 38 Whr L71760-005
Component replacement procedures 31
