Page #65 background imageLoading...
Page #65 background image
1. Start Computer Setup. See Using Computer Setup on page 56.
2. Select Main, select Apply Factory Defaults and Exit, and then select Yes.
NOTE: If you are using arrow keys to highlight your choice, you must then press enter.
NOTE: On select products, the selections might display Restore Defaults instead of Apply Factory
Defaults and Exit.
Your changes go into eect when the computer restarts.
NOTE: Your password settings and security settings are not changed when you restore the factory settings.
Updating the BIOS
Updated versions of the BIOS might be available on the HP website. Most BIOS updates on the HP website are
packaged in compressed les called SoftPaqs.
Some download packages contain a le named Readme.txt, which contains information regarding installing
and troubleshooting the le.
Determining the BIOS version
To decide whether you need to update Computer Setup (BIOS), rst determine the BIOS version on your
computer.
You can access BIOS version information (also known as ROM date and System BIOS) by pressing fn+esc (if you
are already in Windows) or by using Computer Setup.
1. Start Computer Setup. See Using Computer Setup on page 56.
2. Select Main, and then select System Information.
3. To exit Computer Setup menus without saving your changes, select Main, select Ignore Changes and
Exit, and then select Yes.
NOTE: If you are using arrow keys to highlight your choice, you must then press enter.
To check for later BIOS versions, see Preparing for a BIOS update on page 57.
Preparing for a BIOS update
Be sure to follow all prerequisites before downloading and installing a BIOS update.
IMPORTANT: To reduce the risk of damage to the computer or an unsuccessful installation, download and
install a BIOS update only when the computer is connected to reliable external power using the AC adapter. Do
not download or install a BIOS update while the computer is running on battery power, docked in an optional
docking device, or connected to an optional power source. During the download and installation, follow these
instructions:
Do not disconnect power on the computer by unplugging the power cord from the AC outlet.
Do not shut down the computer or initiate Sleep.
Do not insert, remove, connect, or disconnect any device, cable, or cord.
Downloading a BIOS update
After you review the prerequisites, you can check for and download BIOS updates.
Using Computer Setup 57

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Elite Dragonfly G2 and is the answer not in the manual?

HP Elite Dragonfly G2 Specifications

General IconGeneral
4G standardLTE-TDD & LTE-FDD
Antenna type2x2
Wi-Fi standardsWi-Fi 6 (802.11ax)
Bluetooth version5.0
WLAN controller modelIntel Wi-Fi 6 AX201
Mobile network connectionYes
Mobile network generation4G
WLAN controller manufacturerIntel
Color gamut72 %
Display surfaceGloss
RGB color spaceNTSC
Display diagonal13.3 \
Anti-glare screenAlways gives an optimal view, even in direct sunlight.
Display brightness400 cd/m²
Display diagonal (metric)33.8 cm
Processor cache8 MB
Processor cores4
Processor modeli5-1135G7
Processor familyIntel® Core™ i5
Processor threads8
Configurable TDP-up28 W
Processor frequency- GHz
Processor cache typeL3
Configurable TDP-down12 W
Processor boost frequency4.2 GHz
Configurable TDP-up frequency2.4 GHz
Configurable TDP-down frequency0.9 GHz
ECCNo
Memory slots1x SO-DIMM
Internal memory8 GB
Memory clock speed4266 MHz
Memory form factorOn-board
Internal memory typeLPDDR4x-SDRAM
Battery weight240 g
Battery capacity56 Wh
Pointing deviceClickpad
Input device modelHP Premium Collaboration Keyboard
Keyboard special featuresSpill-resistant
SSD capacityThe Solid State Drive's storage capacity in Gigabytes.
SSD interfacePCI Express, NVMe
Storage mediaSSD
Total storage capacity256 GB
Number of SSDs installed1
Color nameGalaxy blue
Form factorConvertible (Folder)
Product typeHybrid (2-in-1)
Product colorBlue
Country of originChina
Market positioningPremium
Original brand nameHP
Speakers manufacturerBang & Olufsen
Charging port typeUSB Type-C
USB 2.0 ports quantity0
Sustainability certificatesENERGY STAR, TCO
HP segmentBusiness
Operating system installedWindows 11 Pro
Discrete graphics card modelNot available
On-board graphics card modelIntel® UHD Graphics
AC adapter power65 W
AC adapter frequency50 - 60 Hz
AC adapter input voltage100 - 240 V
Front camera-
Password protection typeBIOS, Power on, User
Trusted Platform Module (TPM) version2.0
Package depth449 mm
Package width69 mm
Package height305 mm
Weight and Dimensions IconWeight and Dimensions
Depth197.5 mm
Width304.3 mm
Height16.1 mm
Weight990 g
