3. Remove the battery from the computer (3).
To insert the battery, reverse the removal procedures.
Solid-state drive
To remove the M.2 solid-state drive, use this procedure and illustration.
Table
5-3 Solid-state drive descriptions and part numbers
Description Spare part number
2 TB, PCIe-3 × 4, TLC L85358-002
1 TB, PCIe-3 × 4, TLC L85348-002
512 GB, PCIe-3 × 4, TLC L85360-002
512 GB, PCIe-3 × 4, TLC, self-encrypting L85368-002
512 GB, PCIe, value L85364-002
512 GB solid-state drive + 32 GB Optane memory L85366-002
256 GB, PCIe-3 × 4, TLC L85350-002
256 GB, PCIe-3 × 4, TLC, self-encrypting M07245-002
Component replacement procedures 33
