HP Elite Dragonfly G2 User Manual

Table 5-13 System board descriptions and part numbers (continued)
Description Spare part number
Intel Core i7-1185G7 processor with 32 GB of system memory (OSR) M42292-xx1
Intel Core i7-1185G7 processor with 16 GB of system memory (OSR) M42291-xx1
Intel Core i7-1165G7 processor with 32 GB of system memory M42290-xx1
Intel Core i7-1165G7 processor with 16 GB of system memory M42289-xx1
Intel Core i5-1145G7 processor with 16 GB of system memory (OSR) M42288-xx1
Intel Core i5-1145G7 processor with 16 GB of system memory M42287-xx1
Intel Core i5-1145G7 processor with 8 GB of system memory (OSR) M42286-xx1
Intel Core i5-1145G7 processor with 8 GB of system memory M42285-xx1
Intel Core i5-1135G7 processor with 16 GB of system memory M42284-xx1
Intel Core i5-1135G7 processor with 8 GB of system memory M42283-xx1
Intel Core i3-1115G4 processor with 8 GB of system memory M42282-xx1
Before removing the system board, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 30).
2. Remove the bottom cover (Bottom cover on page 30).
3. Disconnect the battery cable from the system board (see Battery on page 31).
4. Remove the audio board (see Audio board on page 41).
When you replace the system board, be sure to remove the following components (as applicable) from the
defective system board and install them on the replacement system board:
● Solid-state drive (see Solid-state drive on page 33).
● Heat sink and fan assembly (Heat sink and fan assembly on page 38).
Remove the system board:
1. Disconnect the following cables from the system board:
● Display cable (ZIF) (1)
● WLAN antennas (2)
● Display cable (3)
● USB board cable (ZIF) (4)
● Keyboard backlight cable (ZIF) (5)
● Extend cable (ZIF) (6)
● Speakers (7)
Component replacement procedures 47

HP Elite Dragonfly G2 Specifications

General

4G standard	LTE-TDD & LTE-FDD
Antenna type	2x2
Wi-Fi standards	Wi-Fi 6 (802.11ax)
Bluetooth version	5.0
WLAN controller model	Intel Wi-Fi 6 AX201
Mobile network connection	Yes
Mobile network generation	4G
WLAN controller manufacturer	Intel
Color gamut	72 %
Display surface	Gloss
RGB color space	NTSC
Display diagonal	13.3 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	400 cd/m²
Display diagonal (metric)	33.8 cm
Processor cache	8 MB
Processor cores	4
Processor model	i5-1135G7
Processor family	Intel® Core™ i5
Processor threads	8
Configurable TDP-up	28 W
Processor frequency	- GHz
Processor cache type	L3
Configurable TDP-down	12 W
Processor boost frequency	4.2 GHz
Configurable TDP-up frequency	2.4 GHz
Configurable TDP-down frequency	0.9 GHz
ECC	No
Memory slots	1x SO-DIMM
Internal memory	8 GB
Memory clock speed	4266 MHz
Memory form factor	On-board
Internal memory type	LPDDR4x-SDRAM
Battery weight	240 g
Battery capacity	56 Wh
Pointing device	Clickpad
Input device model	HP Premium Collaboration Keyboard
Keyboard special features	Spill-resistant
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express, NVMe
Storage media	SSD
Total storage capacity	256 GB
Number of SSDs installed	1
Color name	Galaxy blue
Form factor	Convertible (Folder)
Product type	Hybrid (2-in-1)
Product color	Blue
Country of origin	China
Market positioning	Premium
Original brand name	HP
Speakers manufacturer	Bang & Olufsen
Charging port type	USB Type-C
USB 2.0 ports quantity	0
Sustainability certificates	ENERGY STAR, TCO
HP segment	Business
Operating system installed	Windows 11 Pro
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Front camera	-
Password protection type	BIOS, Power on, User
Trusted Platform Module (TPM) version	2.0
Package depth	449 mm
Package width	69 mm
Package height	305 mm

Weight and Dimensions

Depth	197.5 mm
Width	304.3 mm
Height	16.1 mm
Weight	990 g
