HP Elite Dragonfly G2 User Manual

Table 10-1 Troubleshooting steps for nonvolatile memory usage (continued)
Nonvolatile
memory type Amount (Size)
Does this
memory
store
customer
data?
Does this
memory
retain data
when power
is removed?
What is the
purpose of this
memory?
How is data entered into this
memory?
How is this memory
write-protected?
on the HP website; go to
http://www.hp.com/
support. Select Find your
product, and then follow
the on-screen
instructions.
Intel Management
Engine Firmware
(present only in
select Elite or Z
models. For more
information, go to
http://www.hp.com/
support. Select
Identify your
product for
manuals and
specic product
information, and
then follow the
on-screen
instructions.)
1.5 MB or 7 MB Yes Yes Stores
Management
Engine Code,
Settings,
Provisioning
Data and iAMT
third-party data
store.
Management Engine Code is
programmed at the factory.
Code is updated via Intel
secure rmware update
utility. Unique Provisioning
Data can be entered at the
factory or by an
administrator using the
Management Engine (MEBx)
setup utility. The third-party
data store contents can be
populated by a remote
management console or local
applications that have been
registered by an
administrator to have access
to the space.
The Intel chipset is
congured to enforce
hardware protection to
block all direct read-write
access to this area. An
Intel utility must be used
for updating the
rmware. Only rmware
updates digitally signed
by Intel can be applied
using this utility.
Bluetooth ash
(select products
only)
2 megabits No Yes Stores
Bluetooth
conguration
and rmware.
Bluetooth ash is
programmed at the factory.
Tools for writing data to this
memory are not publicly
available but can be obtained
from the silicon vendor.
A utility must be used for
writing data to this
memory and is made
available through newer
versions of the driver
whenever the ash
requires an upgrade.
802.11 WLAN
EEPROM
4 kilobits to 8
kilobits
No Yes Stores
conguration
and calibration
data.
802.11 WLAN EEPROM is
programmed at the factory.
Tools for writing data to this
memory are not made public.
A utility must be used for
writing data to this
memory and is typically
not made available to the
public unless a rmware
upgrade is necessary to
address a unique issue.
Camera (select
products only)
64 kilobits No Yes Stores camera
conguration
and rmware.
Camera memory is
programmed using a utility
from the device
manufacturer that can be run
from Windows.
A utility must be used for
writing data to this
memory and is typically
not made available to the
public unless a rmware
upgrade is necessary to
address a unique issue.
Fingerprint reader
(select products
only)
512 KB ash Yes Yes Stores
ngerprint
templates.
Fingerprint reader memory is
programmed by user
enrollment in HP
ProtectTools Security
Manager.
Only a digitally signed
application can make the
call to write to the ash.
Nonvolatile memory usage 71

HP Elite Dragonfly G2 Specifications

General

4G standard	LTE-TDD & LTE-FDD
Antenna type	2x2
Wi-Fi standards	Wi-Fi 6 (802.11ax)
Bluetooth version	5.0
WLAN controller model	Intel Wi-Fi 6 AX201
Mobile network connection	Yes
Mobile network generation	4G
WLAN controller manufacturer	Intel
Color gamut	72 %
Display surface	Gloss
RGB color space	NTSC
Display diagonal	13.3 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	400 cd/m²
Display diagonal (metric)	33.8 cm
Processor cache	8 MB
Processor cores	4
Processor model	i5-1135G7
Processor family	Intel® Core™ i5
Processor threads	8
Configurable TDP-up	28 W
Processor frequency	- GHz
Processor cache type	L3
Configurable TDP-down	12 W
Processor boost frequency	4.2 GHz
Configurable TDP-up frequency	2.4 GHz
Configurable TDP-down frequency	0.9 GHz
ECC	No
Memory slots	1x SO-DIMM
Internal memory	8 GB
Memory clock speed	4266 MHz
Memory form factor	On-board
Internal memory type	LPDDR4x-SDRAM
Battery weight	240 g
Battery capacity	56 Wh
Pointing device	Clickpad
Input device model	HP Premium Collaboration Keyboard
Keyboard special features	Spill-resistant
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express, NVMe
Storage media	SSD
Total storage capacity	256 GB
Number of SSDs installed	1
Color name	Galaxy blue
Form factor	Convertible (Folder)
Product type	Hybrid (2-in-1)
Product color	Blue
Country of origin	China
Market positioning	Premium
Original brand name	HP
Speakers manufacturer	Bang & Olufsen
Charging port type	USB Type-C
USB 2.0 ports quantity	0
Sustainability certificates	ENERGY STAR, TCO
HP segment	Business
Operating system installed	Windows 11 Pro
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Front camera	-
Password protection type	BIOS, Power on, User
Trusted Platform Module (TPM) version	2.0
Package depth	449 mm
Package width	69 mm
Package height	305 mm

Weight and Dimensions

Depth	197.5 mm
Width	304.3 mm
Height	16.1 mm
Weight	990 g
