2. Insert a nonmarking, nonconductive, thin tool near the hinge (1) and pull up to release the cover (2).
3. Remove the bottom cover from the computer (3).
To replace the bottom cover, reverse the removal procedures.
Battery
To remove the battery, use this procedure and illustration.
Table
5-2 Battery description and part number
Description Spare part number
Battery, 4 cell, 56 Whr L52581-005
30 Chapter 5 Removal and replacement procedures for authorized service provider parts

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Elite Dragonfly Max and is the answer not in the manual?

HP Elite Dragonfly Max Specifications

General IconGeneral
StorageUp to 2 TB PCIe NVMe SSD
GraphicsIntel Iris Xe Graphics
ProcessorIntel Core i5-1135G7 or i7-1185G7
Display1920 x 1080
RAMUp to 32GB LPDDR4x
Operating SystemWindows 10 Pro
WeightStarting at 2.49 lb (1.13 kg)
Battery4-cell, 56 Wh Li-ion polymer
CameraIR camera
AudioBang & Olufsen
Dimensions1.61 cm
Ports1 x HDMI 2.0, 1 x headphone/mic combo
WirelessIntel Wi-Fi 6 AX201 (2x2) and Bluetooth 5 combo
SecurityHP Sure Sense, HP Sure Click, HP Sure Start
