Table 5-13 System board descriptions and part numbers (continued)
Description Spare part number
Intel Core i7-1185G7 processor with 32 GB of system memory (OSR) M42292-xx1
Intel Core i7-1185G7 processor with 16 GB of system memory (OSR) M42291-xx1
Intel Core i7-1165G7 processor with 32 GB of system memory M42290-xx1
Intel Core i7-1165G7 processor with 16 GB of system memory M42289-xx1
Before removing the system board, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 29).
2. Remove the bottom cover (Bottom cover on page 29).
3. Disconnect the battery cable from the system board (see Battery on page 30).
4. Remove the audio board (see Audio board on page 39).
When you replace the system board, be sure to remove the following components (as applicable) from the
defective system board and install them on the replacement system board:
● Solid-state drive (see Solid-state drive on page 32).
● Heat sink and fan assembly (Heat sink and fan assembly on page 36).
Remove the system board:
1. Disconnect the following cables from the system board:
● Display cable (ZIF) (1)
● WLAN antennas (2)
● Display cable (3)
● USB board cable (ZIF) (4)
● Keyboard backlight cable (ZIF) (5)
● Extend cable (ZIF) (6)
● Speakers (7)
Component replacement procedures 45

HP Elite Dragonfly Max Specifications

General

Storage	Up to 2 TB PCIe NVMe SSD
Graphics	Intel Iris Xe Graphics
Processor	Intel Core i5-1135G7 or i7-1185G7
Display	1920 x 1080
RAM	Up to 32GB LPDDR4x
Operating System	Windows 10 Pro
Weight	Starting at 2.49 lb (1.13 kg)
Battery	4-cell, 56 Wh Li-ion polymer
Camera	IR camera
Audio	Bang & Olufsen
Dimensions	1.61 cm
Ports	1 x HDMI 2.0, 1 x headphone/mic combo
Wireless	Intel Wi-Fi 6 AX201 (2x2) and Bluetooth 5 combo
Security	HP Sure Sense, HP Sure Click, HP Sure Start
