Page #106 background imageLoading...
Page #106 background image
10 HP PC Hardware Diagnostics (UEFI)
HP PC Hardware Diagnostics is a Unied Extensible Firmware Interface (UEFI) that allows you to run diagnostic
tests to determine whether the computer hardware is functioning properly. The tool runs outside the
operating system so that it can isolate hardware failures from issues that are caused by the operating system
or other software components.
When HP PC Hardware Diagnostics (UEFI) detects a failure that requires hardware replacement, a 24-digit
Failure ID is generated. This ID can then be provided to support to help determine how to correct the problem.
NOTE: To start diagnostics on a convertible computer, your computer must be in notebook mode and you
must use the keyboard attached.
To start HP PC Hardware Diagnostics (UEFI), follow these steps:
1. Turn on or restart the computer, quickly press esc.
NOTE: The HP PC Hardware Diagnostics (UEFI) download instructions are provided in English only, and
you must use a Windows computer to download and create the HP UEFI support environment because
only .exe les are oered.
2. Press or tap f2.
The BIOS searches three places for the diagnostic tools, in the following order:
a. Connected USB drive
NOTE: To download the HP PC Hardware Diagnostics (UEFI) tool to a USB drive, see Downloading
HP PC Hardware Diagnostics (UEFI) to a USB device on page 96.
b. Hard drive
c. BIOS
3. When the diagnostic tool opens, select the type of diagnostic test you want to run, and then follow the
on-screen instructions.
NOTE: If you need to stop a diagnostic test, press esc.
Downloading HP PC Hardware Diagnostics (UEFI) to a USB device
NOTE: The HP PC Hardware Diagnostics (UEFI) download instructions are provided in English only, and you
must use a Windows computer to download and create the HP UEFI support environment because only .exe
les are oered.
There are two options to download HP PC Hardware Diagnostics to a USB device.
Download the latest UEFI version
1. Go to http://www.hp.com/go/techcenter/pcdiags. The HP PC Diagnostics home page is displayed.
2. In the HP PC Hardware Diagnostics section, click the Download link, and then select Run.
96 Chapter 10 HP PC Hardware Diagnostics (UEFI)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 745 G3 and is the answer not in the manual?

HP EliteBook 745 G3 Specifications

General IconGeneral
Form factorClamshell
Product typeLaptop
Product colorBlack, Silver
Country of originChina
Memory slots2x SO-DIMM
Internal memory8 GB
Memory clock speed1600 MHz
Memory form factorSO-DIMM
Internal memory typeDDR3L-SDRAM
Maximum internal memory16 GB
Memory layout (slots x size)1 x 8 GB
3DNo
AC adapter includedYes
Intel segment taggingEnterprise
SSD capacityThe Solid State Drive's storage capacity in Gigabytes.
Storage mediaSSD
Total storage capacity256 GB
Compatible memory cardsSD, SDHC, SDXC
Number of SSDs installed1
Panel typeSVA
Display surfaceMatt
Display diagonal14 \
Native aspect ratio16:9
Discrete graphics card modelNot available
On-board graphics card modelAMD Radeon R7
On-board graphics card base frequency800 MHz
Number of built-in speakers2
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 5 (802.11ac)
Bluetooth version4.0
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Charging port typeDC-in jack
USB 2.0 ports quantity0
Sustainability certificatesENERGY STAR
Cables includedAC
AC adapter power45 W
Battery capacity46 Wh
Battery life (max)- h
Number of battery cells3
Keyboard layout-
Pointing deviceTouchpad
Processor cache3 MB
Processor modelPRO A12-8800B
Processor familyAMD PRO A12
Processor threads4
Processor frequency2.1 GHz
Processor cache typeL2
Processor manufacturerAMD
Processor boost frequency3.4 GHz
Operating system installedWindows 7 Professional
Operating system architecture64-bit
Weight and Dimensions IconWeight and Dimensions
Depth237 mm
Width338 mm
Height18.9 mm
Weight1540 g
